OFP-LED

$500.00$900.00

36″ (OFP-36LED) / 42″ (OFP-42LED) / 50″ (OFP-50LED) / 60″ (OFP-60LED) / 72″ (OFP-72LED) wall mounted and built-in style fireplace by ORCTECH with vent located at the bottom front

  • Wall mounted & built-in style Fireplaces
  • Includes LED 9 colour flame, one colour cycle and one off status and the same applies to the side lighting
  • Two stage fan-forced air heater which you may use with the heater or without for ambiance
  • Automatic overheating protection with timer of 1 hour increments up to 9 hours
  • Has 3 ember bed selections which plastic crystals, one piece log / stone consist
  • Integrated remote control and touch control pad
  • Vent is located at the Bottom Front of the fireplaces
  • Available in Black Colour Trim Only
Clear
SKU: N/A Category:

Description

Available in  5 sizes:

  • 36″ (OFP-36LED) / 42″ (OFP-42LED) / 50″ (OFP-50LED) / 60″ (OFP-60LED) / 72″ (OFP-72LED) wall mounted and built-in style fireplace by ORCTECH with vent located at the bottom front

Installation

  • Please take out the foam that is inside the unit before using the heater
  • Remove the glass panel first, set the fire box into the wall.
  • Secure the side trim pieces on the wall with screws.
  • Reinstall the glass panel onto the firebox with screws.
  1. Remove the outer glass around the bracket, mounting screws
  2. Remove the outer glass
  3. Take out the foam
  4. Install the outer glass to the appliance:
    • Lift glass panel and line up with the top bracket, fasten panel to the appliance.
    • Screw the brackets to appliance with mounting screws
  5. Be cautious about the outer glass bracket screws

Glass Particles Installation

  1. To remove the outer glass around the bracket, undo the mounting screws
  2. Remove the outer glass
  3. Adjust the screws and carefully take out the log set
  4. Gently put the glass crystals into place
  5. Be cautious about the outer glass bracket screws
